218.1637 – 16A 3P+N+E IP67 Male Plug | Scame
Order code
R234,15
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
16A 3P+N+E IP67 Male Plug — Scame order code 218.1637. Rated current 16 A; 3P+N+E; insulation voltage 690 V AC; IP67 / IP68 / IP69.
Download certifications (opens in a new tab)Download datasheet (opens in a new tab)Download instructions (opens in a new tab)
Accessories & add-ons 4
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised ElectroMechanica distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
218.1637 — 16A 3P+N+E IP67 Male Plug by Scame.
Industrial plugs and sockets Optima series Male plugs (straight cable exit) table.
Key specifications: rated current 16 A; 3P+N+E; insulation voltage 690 V AC; IP67 / IP68 / IP69; IK08; operating temperature −25 … +40 °C; Engineering plastic (halogen free).
Ordering information
- Order code:
218.1637 - Manufacturer: Scame
- Supplied: each
- Datasheet: manufacturer datasheet for 218.1637
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Order code | Filter products by 218.1637 |
|---|---|
| Product name | Filter products by 16A 3P+N+E IP67 Male Plug |
| Brand | Filter products by Scame |
| Product type | Filter products by Male plug |
| Product series | Filter products by OPTIMA |
Electrical ratings
| Number of poles | Filter products by 3P+N+E |
|---|---|
| Rated current (Iu) | Filter products by 16 A |
| Rated insulation voltage | Filter products by 690 V AC |
Sensing & measurement
| Pin configuration | Filter products by 5pin |
|---|
Mechanical & mounting
| Material | Filter products by Engineering plastic (halogen free) |
|---|
Wiring & termination
| Cable inlet | Filter products by External cable stay with tulip clamping IP67 gland |
|---|---|
| Cable outlet | Filter products by Straight |
Environment & protection
| Degree of protection (IP) | Filter products by IP67 / IP68 / IP69 |
|---|---|
| Impact resistance (IK) | Filter products by IK08 |
| Operating temperature | Filter products by −25 … +40 °C |
| Glow wire test | Filter products by 650/850°C |
Documents
| Datasheet | Download datasheet |
|---|---|
| Certifications | Download certifications |
| Instructions for use | Download instructions |
Other specifications
| Voltage range | Filter products by 380-480V |
|---|---|
| Hour position | Filter products by 6h |
