BG09T4D048 – 20A 4P Mini Cont. 4NO 48VDC | Lovato Electric

BG09T4D048 — 20A 4P Mini Cont. 4NO 48VDC by Lovato Electric. Listed under Contactors & Accessories on the Lovato Electric catalogue at RMS-EM.Africa.

About BG09T4D048

BG series mini contactors The main feature of the BG mini contactor is the compact size so its main use is in applications where the electric circuit is compressed because of the available space,for instance on small machine tools, air conditioning, automatic doors or gates, lighting etc. Use in more complex industrial circuitry is also possible for small control loads. These mini contactors can be equipped with accessories or thermal overload relays as well as connected with motor protection circuit breakers. Key features Four-pole mini-contactors AC and DC versions of same size Mechanical interlock only 5mm deep Quick connect – snap on accessory mounting Up to four auxiliary contacts can be mounted Highly conductive auxiliary contacts with four contact points Quick connect – snap on accessory mounting Up to four auxiliary contacts can be mounted Highly conductive auxiliary contacts with four contact points.

BG09T4D048 key specifications

Key specifications: rated current 20 A; AC-1 rating 14 kW at 400 V; 4P; control voltage 48 V; 4 NO contacts.

Ordering information for BG09T4D048

• Order code: BG09T4D048
• Manufacturer: Lovato Electric
• Supplied: each
• Datasheet: manufacturer datasheet for BG09T4D048

Ordering options in this range

Same product, different coil / control voltage:

• BG09T4A024 — 24 V
• BG09T4A110 — 110 V
• BG09T4A230 — 230 V
• BG09T4D012 — 12 V
• BG09T4D060 — 60 V

BG09T4D048 — frequently asked questions

What is the rated current of BG09T4D048?

BG09T4D048 is rated 20 A.

What coil or control voltage does BG09T4D048 use?

BG09T4D048 is supplied with a 48 V coil. Other coil voltages in the range appear under “Ordering options” above where the catalogue lists them.

How many poles does BG09T4D048 have?

BG09T4D048 is a 4P device.

Where is the datasheet for BG09T4D048?

The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Lovato Electric publishes them.

Is BG09T4D048 a genuine Lovato Electric product?

Yes. BG09T4D048 is supplied through the manufacturer’s authorised channel with the standard Lovato Electric warranty, and every order is confirmed against stock before payment.
