| Rated current (Iu) | Filter products by 16 A |
|---|---|
| Rated operational voltage | Filter products by 230 V |
| Number of poles | Filter products by 2P |
| Coil voltage (Uc) | Filter products by 230 V AC |
| Supply voltage | Filter products by 230 V |
| Contact configuration | Filter products by 1 NO + 1 NC |
HagerModular contactors & RelaysTimers & Control Relays
ERC216 – Relay 16A 2NO 230VAC MAN Override | Hager
Order code
R477,75
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Relay 16A 2NO 230VAC MAN Override — Hager order code ERC216. Rated current 16 A; AC-1 rating 16 kW at 400 V; 2P; rated operational voltage 230 V.
Download certifications (opens in a new tab)Download datasheet (opens in a new tab)
Accessories & add-ons 3
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised ElectroMechanica distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
ERC216 — Relay 16A 2NO 230VAC MAN Override, a modular standard contactor by Hager.
Modular contactors Features: Four ratings: 16A, 25A, 40A, 63A Modular DIN rail mounting (same cut-out as MCBs) One and two module contactors feature economy low consumption, low heat dissipation coils.
Key specifications: rated current 16 A; AC-1 rating 16 kW at 400 V; 2P; rated operational voltage 230 V; 230 V AC coil; 50 / 60 Hz; 1 NO + 1 NC contacts; operating temperature −10 … +50 °C.
Ordering information
- Order code:
ERC216 - Manufacturer: Hager
- Supplied: each
- Datasheet: manufacturer datasheet for ERC216
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Order code | Filter products by ERC216 |
|---|---|
| Product name | Filter products by Relay 16A 2NO 230VAC MAN Override |
| Brand | Filter products by Hager |
| Product type | Filter products by Modular standard contactor |
Electrical ratings
| Number of poles | Filter products by 2P |
|---|---|
| Number of modules | Filter products by 1 |
| Rated current (Iu) | Filter products by 16 A |
| Rated operational voltage | Filter products by 230 V |
| Supply voltage | Filter products by 230 V |
| Rated frequency | Filter products by 50 / 60 Hz |
| Frequency | Filter products by 50/60 Hz |
Power & coil
| Coil voltage (Uc) | Filter products by 230 V AC |
|---|---|
| Rated power ac1 | Filter products by 16A |
| Rating AC-1 at 400 V | Filter products by 16 kW |
Contacts, control & I/O
| Contact configuration | Filter products by 1 NO + 1 NC |
|---|
Wiring & termination
| Cross section flexible cable | Filter products by 1 / 6mm² |
|---|---|
| Cross section rigid cable | Filter products by 1 / 10mm² |
Environment & protection
| Operating temperature | Filter products by −10 … +50 °C |
|---|
Documents
| Datasheet | Download datasheet |
|---|---|
| Certifications | Download certifications |
| Instructions for use | Download instructions |
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
