TeknomegaDistribution blocks & Busbar supportsTermination & Wiring
ISO2140 – Spacer Column – Black – H20mm -M6 | Teknomega
Order code
R52,50
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
Spacer Column – Black – H20mm -M6 — Teknomega order code ISO2140. Rated voltage 1000/1500 V AC/DC; operating temperature −40 … +130 °C; Black; Polyamide 66.
Download certifications (opens in a new tab)Download datasheet (opens in a new tab)Download instructions (opens in a new tab)
Accessories & add-ons 8
- 7x20mm Adhesive LABEL(24000/roll)8401010WPYGR12 390,00Add
- 9x38mm Adhesive LABEL(13330/roll)8400094WPYGR14 595,00Add
- 9x15mm Adhesive LABEL(26660/roll)8400092WPYGR13 650,00Add
- 40x90mm Adhesive LABEL(1860/roll)8400083WPYGR14 490,00Add
- 25x45mm Adhesive LABEL(5710/roll)8400073WPYGR14 910,00Add
- 30x80mm Adhesive LABEL(2420/roll)8400072WPYGR12 705,00Add
- 40x80mm Adhesive LABEL(2800/roll)8400051WPYGR18 480,00Add
- 30x30mm Adhesive LABEL(2420/roll)8400042WPYGR8 316,00Add
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised ElectroMechanica distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
ISO2140 — Spacer Column – Black – H20mm -M6, a spacing columns (injection moulded) by Teknomega.
Please note that prices of copper products are based on the London Metal Exchange and will vary from time to time and may not be in line with our printed catalogue. brbr CLN series – spacer columns table.
Key specifications: rated voltage 1000/1500 V AC/DC; operating temperature −40 … +130 °C; Black; Polyamide 66; to IEC/EN60004-1 and IEC/EN 61439-1.
Ordering information
- Order code:
ISO2140 - Manufacturer: Teknomega
- Supplied: each
- Datasheet: manufacturer datasheet for ISO2140
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Order code | Filter products by ISO2140 |
|---|---|
| Product name | Filter products by Spacer Column – Black – H20mm -M6 |
| Brand | Filter products by Teknomega |
| Product type | Filter products by Spacing columns (injection moulded) |
| Product series | Filter products by CLN series |
Electrical ratings
| Rated voltage (Ue) | Filter products by 1000/1500 V AC/DC |
|---|
Mechanical & mounting
| Height | Filter products by 20 mm |
|---|---|
| Threaded | Filter products by M6 |
| Threaded inserts | Filter products by Galvanized steel |
| Diameter width socket o d | Filter products by 20 mm |
| Material | Filter products by Polyamide 66 |
| Insulation | Filter products by Polyamide 66 fibreglass reinforced (30%) (Halogen free) |
| Colour | Filter products by Black |
| Torque nm | Filter products by 8 |
Environment & protection
| Operating temperature | Filter products by −40 … +130 °C |
|---|---|
| Working temperature | Filter products by -40°C – 130°C |
| Self extinguishing | Filter products by VO-UL94 |
| Glow wire test | Filter products by 960°C |
Standards & certification
| Conformity to standards | Filter products by IEC/EN60004-1 and IEC/EN 61439-1 |
|---|
Documents
| Datasheet | Download datasheet |
|---|---|
| Certifications | Download certifications |
| Instructions for use | Download instructions |
Other specifications
| Diameter | Filter products by Ø20mm |
|---|
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Accessories & add-ons
8401010WPYG7x20mm Adhesive LABEL(24000/roll)R12 390,00View product- 8400094WPYG9x38mm Adhesive LABEL(13330/roll)R14 595,00View product
- 8400092WPYG9x15mm Adhesive LABEL(26660/roll)R13 650,00View product
- 8400083WPYG40x90mm Adhesive LABEL(1860/roll)R14 490,00View product
- 8400073WPYG25x45mm Adhesive LABEL(5710/roll)R14 910,00View product
- 8400072WPYG30x80mm Adhesive LABEL(2420/roll)R12 705,00View product
- 8400051WPYG40x80mm Adhesive LABEL(2800/roll)R18 480,00View product
- 8400042WPYG30x30mm Adhesive LABEL(2420/roll)R8 316,00View product
Similar items
79448NH00 Fuse Grip LUG CoverR64,05View product
3111010×38 1P Cylindrical Fuse HolderR82,95View product- 79449NH1-3 Fuse Grip LUG CoverR85,05View product
01573END Covers for 01495 SupportR107,00View product
3157210×38 1P BAR MNT 20mm Fuse HolderR118,65View product- 3157010×38 1P BAR MNT 30mm Fuse HolderR120,75View product
01026Support for Reserve SectionR179,00View product
016011P Universal Busbar SupportR214,00View product
More in Distribution blocks & Busbar supports
33341END Cover 185mm (2pcs)R1 207,50View product
33222NH00 3P Fuse SW Disconnector 160AR1 449,00View product- 33217NH000 3P Fuse SW Disconn 125AR1 711,50View product
33204NH4 3P Fuse SW Disconnector 1600AR37 695,00View product- 33203NH3 3P Fuse SW Disconnector 630AR9 586,50View product
- 33202NH2 3P Fuse SW Disconnector 400AR7 476,00View product
- 33201NH1 3P Fuse SW Disconnector 250AR4 641,00View product
3112322×58 3P Cylindrical Fuse HolderR2 583,00View product
Alternatives on our other RMS storefronts
RMS supplies each manufacturer range from its own storefront. These links open a different RMS site in a new tab.
Quick answers
What is ISO2140?
ISO2140 is the order code for ISO2140 – Spacer Column – Black – H20mm -M6 | Teknomega. It belongs to our Distribution blocks & Busbar supports range. RMS-EM.Africa supplies it as an authorised ElectroMechanica distributor, so it is genuine product with the manufacturer's warranty.
Is it available?
It is listed as in stock. Availability is re-confirmed on every order before any payment is taken, so what you order is what actually ships.
How do I get a formal quotation?
Use "Add to quote" and submit the quote basket. The RMS team prices every line, confirms stock, and emails you a formal quotation with written lead times — and you can accept it online to turn it into an order.
Do I pay when I order?
No. Checkout submits the order without payment; we confirm stock for every line first, then email you a secure payment link for the order.
