Lovato ElectricLevel control relaysTimers & Control Relays
LVM40A415 – Liquid Level Control RELAY-5PROBE | Lovato Electric
Order code
List R2 730,00 Your price R1 911,00
Per unit · volume pricing available on request
excl. VAT R2 197,65 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Liquid Level Control RELAY-5PROBE — Lovato Electric order code LVM40A415. Rated current 5 A; supply 400 V.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Download certifications (opens in a new tab)Download datasheet (opens in a new tab)Download instructions (opens in a new tab)
Select a variant in this series
Supply voltage400 V6 options
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised ElectroMechanica distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
LVM40A415 — Liquid Level Control RELAY-5PROBE by Lovato Electric. Listed under Level control relays on the Lovato Electric catalogue at RMS-EM.Africa.
About LVM40A415
LVM series level controls relays LVM40 five detecting probes (Min1, Max1, Min2, Max2 and Com) Adjustments: Sensitivity 2.5 – 200Ω (seperate adjustment for Max for foam detection) Probe signal delay 1-10s – pump start delay 0 – 30min Selectable: Standard emptying and alarms (or) standard filling and alarms Emptying with priority start-up change control Filling with priority start-up change control Well draining and tank filling and alarms General features: Level monitoring for electrically conductive liquids Modular DIN rail mounting (aligns with standard MCB's) Double insulation between supply, electrodes and output relay.
LVM40A415 key specifications
Key specifications: rated current 5 A; supply 400 V.
Ordering information for LVM40A415
- Order code:
LVM40A415 - Manufacturer: Lovato Electric
- Supplied: each
- Datasheet: manufacturer datasheet for LVM40A415
LVM40A415 — frequently asked questions
What is the rated current of LVM40A415?
LVM40A415 is rated 5 A.
Where is the datasheet for LVM40A415?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Lovato Electric publishes them.
Is LVM40A415 a genuine Lovato Electric product?
Yes. LVM40A415 is supplied through the manufacturer’s authorised channel with the standard Lovato Electric warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Order code | LVM40A415 |
|---|---|
| Product name | Filter products by Liquid Level Control RELAY-5PROBE |
| Brand | Filter products by Lovato Electric |
| Product type | Filter products by 5 probe liquid level control relay |
| Product series | Filter products by LVM |
Electrical ratings
| Rated current (Iu) | Filter products by 5 A |
|---|---|
| Supply voltage | Filter products by 400 V |
Mechanical & mounting
| Module width mm | Filter products by 54 (aligns with standard MCB's) |
|---|
Documents
| Datasheet | Download datasheet |
|---|---|
| Certifications | Download certifications |
| Instructions for use | Download instructions |
Other specifications
| Functions | Filter products by Emptying or filling |
|---|
