R2U110A – Unqual Repeat Timer 110VAC | Electro

R2U110A — Unqual Repeat Timer 110VAC by Electro. Listed under Plug-in timing & Monitoring devices on the Electro catalogue at RMS-EM.Africa.

About R2U110A

Unequal Repeating The Electro 11 pin plug-in range of control and timing devices are to be installed into a standard 11 pin base making installation easy and convenient. Microprocessor based unequal repeating timer with two selectable modes of operation and eight separately selectable ON and OFF time ranges from 0.3sec – 60hrs. The ON and OFF times can only be selected from the A or B range and not both. Extensive applications due to combination of functions and time ranges. Due to the advanced design of the unit a high accuracy can be achieved. Any adjustable on the front potentiometer after the supply is applied is not acknowledged. This prevents unwanted changes of the time range. The ON and OFF times can be adjusted independently. Features: Repeatable deviation: 0.2% Microprocessor based design Selectable ON or OFF time first Time range 0.3 second – 60 hours Power supply ON and Relay ON LEDs Rear DIP switch selection of 8 separate ON and OFF timer ranges Separate potentiometer adjustable time settings for ON and OFF period.

R2U110A key specifications

Key specifications: supply 110 V.

Ordering information for R2U110A

• Order code: R2U110A
• Manufacturer: Electro
• Supplied: each
• Datasheet: manufacturer datasheet for R2U110A

R2U110A — frequently asked questions

Where is the datasheet for R2U110A?

The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Electro publishes them.

Is R2U110A a genuine Electro product?

Yes. R2U110A is supplied through the manufacturer’s authorised channel with the standard Electro warranty, and every order is confirmed against stock before payment.
