HagerModular contactors & RelaysTimers & Control Relays
ERD225SDC – 25A 2NO 24VDC Cont. MAN Override | Hager
Order code
List R622,65 Your price R435,85
Per unit · volume pricing available on request
excl. VAT R501,23 incl.
Listed in stock — availability is re-confirmed on every order
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
25A 2NO 24VDC Cont. MAN Override — Hager order code ERD225SDC. Rated current 25 A; AC-1 rating 25 kW at 400 V; 2P; rated operational voltage 230 V.
In stock — 1–2 working days if stocked locally, 3–5 working days if sourced
Download certifications (opens in a new tab)Download datasheet (opens in a new tab)
Select a variant in this series
Every option is a reference in this catalogue. A faded option changes more than one value — its nearest reference is linked.
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised ElectroMechanica distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
ERD225SDC — 25A 2NO 24VDC Cont. MAN Override, a low noise modular standard contactor by Hager. Listed under Modular contactors & Relays on the Hager catalogue at RMS-EM.Africa.
About ERD225SDC
Modular contactors with low noise coil Features: No humming while energised / low switching noise Modular DIN rail mounting (same cut-out as MCBs).
ERD225SDC key specifications
Key specifications: rated current 25 A; AC-1 rating 25 kW at 400 V; 2P; rated operational voltage 230 V; 24 V DC coil; supply 24 V; 2 NO contacts; operating temperature −10 … +50 °C.
Ordering information for ERD225SDC
- Order code:
ERD225SDC - Manufacturer: Hager
- Supplied: each
- Datasheet: manufacturer datasheet for ERD225SDC
Ordering options in this range
Same product, different coil / control voltage:
ERC225S— 230 V ACERL625SDC— 12 V DC
ERD225SDC — frequently asked questions
What is the rated current of ERD225SDC?
ERD225SDC is rated 25 A.
What coil or control voltage does ERD225SDC use?
ERD225SDC is supplied with a 24 V DC coil. Other coil voltages in the range appear under “Ordering options” above where the catalogue lists them.
How many poles does ERD225SDC have?
ERD225SDC is a 2P device.
Where is the datasheet for ERD225SDC?
The manufacturer datasheet is linked under “Ordering information” above; the product page also carries the manufacturer’s documents where Hager publishes them.
Is ERD225SDC a genuine Hager product?
Yes. ERD225SDC is supplied through the manufacturer’s authorised channel with the standard Hager warranty, and every order is confirmed against stock before payment.
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Order code | ERD225SDC |
|---|---|
| Product name | Filter products by 25A 2NO 24VDC Cont. MAN Override |
| Brand | Filter products by Hager |
| Product type | Filter products by Low noise modular standard contactor |
Electrical ratings
| Number of poles | Filter products by 2P |
|---|---|
| Number of modules | Filter products by 1 |
| Rated current (Iu) | Filter products by 25 A |
| Rated operational voltage | Filter products by 230 V |
| Supply voltage | Filter products by 24 V |
| Frequency | Filter products by 0/0 Hz |
Power & coil
| Coil voltage (Uc) | Filter products by 24 V DC |
|---|---|
| Rated power ac1 | Filter products by 25A |
| Rating AC-1 at 400 V | Filter products by 25 kW |
Contacts, control & I/O
| Contact configuration | Filter products by 2 NO |
|---|
Wiring & termination
| Cross section flexible cable | Filter products by 1 / 6mm² |
|---|---|
| Cross section rigid cable | Filter products by 1 / 10mm² |
Environment & protection
| Operating temperature | Filter products by −10 … +50 °C |
|---|
Documents
| Datasheet | Download datasheet |
|---|---|
| Certifications | Download certifications |
| Instructions for use | Download instructions |
