| Rated current (Iu) | Filter products by 16 A |
|---|---|
| Number of poles | Filter products by 1P |
| Max break capacity | Filter products by 4.5 kA |
| Tripping curve | Filter products by C |
| Product series | Filter products by MJT series |
HagerMiniature circuit breakersPower Distribution & Protection
MJT716 – 16A 1PH+N 4.5KA C-curve MCB | Hager | EM
Order code
R313,95
Excluding VAT · per unit · volume pricing available on request
Listed in stock — availability is re-confirmed on every order
16A 1PH+N 4.5KA C-curve MCB — Hager order code MJT716. Rated current 16 A; 1P; breaking capacity 4.5 kA; C curve.
Download datasheet (opens in a new tab)Download certifications (opens in a new tab)
Ordering & delivery
- Contact us for bulk pricing, lead times and ordering codes.
- Minimum order: 1 unit.
- Manufacturer's standard warranty applies.
- Collection from our branch, delivery in the Johannesburg area, and export across Africa on request.
- Some items are held off-site rather than in our own warehouse — availability is confirmed on every order.
- Authorised ElectroMechanica distributor
- Genuine product with manufacturer warranty
- Formal quotations with written lead times
Overview
MJT716 — 16A 1PH+N 4.5KA C-curve MCB, a miniature circuit breaker by Hager.
Miniature circuit breakers (MCB's) Protection and control of circuits against overload and short circuits Suitable for domestic and commercial installations. Suitable for domestic and commercial installations. Features: Accepts clip-on: auxiliaries, shunt trip, undervoltage and earth leakage Trip indication – yellow flag on toggle indicates either "overload" or "short circuit" trip.
Key specifications: rated current 16 A; 1P; breaking capacity 4.5 kA; C curve; operating temperature −25 … +60 °C; 1 modules wide; to 60947-2 / SANS556.
Ordering information
- Order code:
MJT716 - Manufacturer: Hager
- Supplied: each
- Datasheet: manufacturer datasheet for MJT716
Technical specifications
Data supplied by the manufacturer. Confirm against the official datasheet before ordering.
Identification & ordering
| Order code | Filter products by MJT716 |
|---|---|
| Product name | Filter products by 16A 1PH+N 4.5KA C-curve MCB |
| Brand | Filter products by Hager |
| Product type | Filter products by Miniature circuit breaker |
| Product series | Filter products by MJT series |
Electrical ratings
| Number of poles | Filter products by 1P |
|---|---|
| Number of modules | Filter products by 1 |
| Rated current (Iu) | Filter products by 16 A |
| Tripping curve | Filter products by C |
| Max break capacity | Filter products by 4.5 kA |
Contacts, control & I/O
| Neutral position | Filter products by Left |
|---|
Mechanical & mounting
| Width in 17 5mm modules | Filter products by 1 |
|---|
Environment & protection
| Operating temperature | Filter products by −25 … +60 °C |
|---|
Standards & certification
| Conformity to standards | Filter products by 60947-2 / SANS556 |
|---|---|
| SANS / IEC standard | Filter products by 60947-2 / SANS556 |
Documents
| Datasheet | Download datasheet |
|---|---|
| Certifications | Download certifications |
| Instructions for use | Download instructions |
Documents
Published by the manufacturer for this part. Each one opens in a new tab.
